**Momentum
Disk Analysis**.

The
helicopter rotor can be idealised as a “momentum disk”. It
imparts a uniform velocity (v_{i}) to the airflow creating a
change in momentum which will result in an upward thrust (T).

**Hover**

For
the hover case air is sucked in from all directions so the farfield
inlet velocity is effectively zero, accelerated to v_{i} at
the disk and then propelled to a final slipstream velocity of v_{s}
below.

If the area of the disk is A then the mass flow of air being accelerated is

The change in momentum of the stream will be and this will be equal to the force produced, the thrust.

.

The change in Energy per unit time of the stream will be

The work done per unit time on the air by the rotor thrust is

hence

giving

.

Hence thrust of the ideal rotor in hover is

.

As the thrust is required to be equal to the weight of the vehicle, it is possible to use this equation to predict the induced flow required to be produced by the rotor,

**Climb**

For the case where the helicopter is climbing, the rotor will capture flow from a fixed area above and accelerate this to a final slipstream velocity. The momentum balance will be slightly different as the incoming air has an initial momentum due to the helicopter climb speed and the rotor is just augmenting this.

The mass flow rate through the disk will be,

.

The thrust due to momentum change will be,

.

The variation of pressure will drop below atmospheric above the disk, increas due to the energy input of the disk and then drop bad to atmospheric in the slipstream.

Applying and Energy balance will again lead to so that,

.

Rearranging gives,

Solving
this quadratic equation for V_{i} gives,

or

The required variation in induced velocity for climb is shown in the following figure,

Less induced velocity is required for climb as the momentum change applied to a higher initial velocity is more effective.

**Descent**

Descent can be analysed by using a negative value of Vc in the above equations. However there are physical limits on this approach due to the changing flow pattern. As the capture area is now below, problems will arise as the rotor is now capturing its own wake an recirculating it to create momentum change. Eventually at a higher rate of descent the system will become closed and the rotor will simply recycle its own wake ('ring state'). In this condition there is no momentum change and hence no thrust.

A) slowly descending rotor. (Positive Thrust)

B) moderate rate descent (Ring State, no thrust).

C) fast descent rate ( windmilling )

If the above stable ring flow state can be avoided, a fast descent can be achieved which puts the rotor in to a windmill state. Capture area is still below but rotor is absorbing momentum from the stream and a divergent slip stream appears above. This negative change in momentum will again produce a thrust (a vertical drag). This flow state can be used for autorotation of the blades.

**Power
required.**

Engine power is required to be supplied to the disk in order to produce the required thrust. There will be two components of power requirement in this simple analysis. Power is required to produce the momentum change ( ) and power is required to make the helicopter climb ( ). Neglecting power losses in transmission, fuselage drag components, blade profile drag power, etc. The the power required for the operation of the rotor will be,

.

Again assuming climb rates are small so thrust approximately equals weight , the variation of power required for different climb rates is shown in the following figure.
